You can rest assured to buy the Gangxin Copper Compression T Fitting produced by our factory. This product is made with the latest environmental protection technology, high product density, strong pressure resistance, in line with ROHS and REACH environmental protection testing, beautiful appearance, convenient installation size, advanced technology;
Copper Compression T Fitting is an important pipe fitting, is widely used in the connection of refrigeration, heating products. It uses TP2 copper pipe as the material, has good thermal conductivity and corrosion resistance, which makes it in the air conditioning heat exchanger, water heater and other products occupy an important position in the manufacture. copper's excellent thermal conductivity is an essential material for refrigeration and heating products. and its corrosion resistance ensures that products such as water heaters have longer service life and is more cost-effective. In addition, copper as a healthy material, its unique antibacterial, sterilization, antibacterial properties become the preferred material for water appliances industry such as drinking fountains.
The specifications and models of the Copper Compression T Fitting are various, , such as φ28.622 and φ6.350.8, these specifications of pipe fittings are connected with the copper pipe by welding, is an indispensable component in the connection of refrigeration pipe and water heating pipe. The product features of copper T-tee include that the thickness of copper pipe used depends on the diameter. The larger the diameter , the thicker the wall thickness of copper pipe, to ensure product quality. , for example, in general, it is enough to use 1mm thick copper pipe for a diameter below φ22.3, and 1.5mm thick copper pipe for a diameter of φ35 and above. This design guarantees the quality and durability of the fittings. In addition, Copper Compression T Fitting has also passed ROHS,REACH certification, strict production technology, including environmental cleaning technology, does not damage the copper, pipe wall is clean, the inner wall has no black spots, no impurities.
|
D |
A(Φ) |
B(Φ) |
C(Φ) |
E |
F |
G |
X |
Y |
Z |
L |
H |
T |
|
|
GX-T-01 |
4.76 |
4.86 |
4.86 |
4.86 |
6 |
6 |
6 |
6.4 |
6.4 |
8.4 |
24.8 |
14.4 |
0.41 |
|
GX-T-02 |
5 |
5.1 |
5.1 |
5.1 |
6 |
6 |
6 |
6.5 |
6.5 |
8.5 |
25.0 |
14.5 |
0.41 |
|
GX-T-03 |
6 |
6.1 |
6.1 |
6.1 |
6 |
6 |
6 |
7.0 |
7.0 |
9.0 |
26.0 |
15.0 |
0.41 |
|
GX-T-04 |
6.35 |
6.45 |
6.45 |
6.45 |
6 |
6 |
6 |
7.2 |
7.2 |
9.2 |
26.4 |
15.2 |
0.41 |
|
GX-T-05 |
7 |
7.1 |
7.1 |
7.1 |
7 |
7 |
7 |
7.5 |
7.5 |
9.5 |
29.0 |
16.5 |
0.5 |
|
GX-T-06 |
7.94 |
8.04 |
8.04 |
8.04 |
8 |
8 |
8 |
8.0 |
8.0 |
10.0 |
31.9 |
18.0 |
0.5 |
|
GX-T-07 |
9.52 |
9.62 |
9.62 |
9.62 |
9 |
9 |
9 |
8.8 |
8.8 |
10.8 |
35.5 |
19.8 |
0.55 |
|
GX-T-08 |
12.70 |
12.8 |
12.8 |
12.8 |
10 |
10 |
10 |
10.4 |
10.4 |
12.4 |
40.7 |
22.4 |
0.7 |
|
GX-T-09 |
15.88 |
15.98 |
15.98 |
15.98 |
11 |
11 |
11 |
11.9 |
11.9 |
13.9 |
45.9 |
24.9 |
0.8 |
|
GX-T-10 |
19.05 |
19.15 |
19.15 |
19.15 |
12 |
12 |
12 |
13.5 |
13.5 |
15.5 |
51.1 |
27.5 |
0.8 |
|
GX-T-11 |
22.23 |
22.33 |
22.33 |
22.33 |
13 |
13 |
13 |
15.1 |
15.1 |
17.1 |
56.2 |
30.1 |
1.0 |
|
GX-T-12 |
25.40 |
25.5 |
25.5 |
25.5 |
14 |
14 |
14 |
16.7 |
16.7 |
18.7 |
61.4 |
32.7 |
1.0 |
|
GX-T-13 |
28.58 |
28.68 |
28.68 |
28.68 |
15 |
15 |
15 |
18.3 |
18.3 |
20.3 |
66.6 |
35.3 |
1.0 |
|
GX-T-14 |
31.75 |
31.85 |
31.85 |
31.85 |
18 |
18 |
18 |
19.9 |
19.9 |
21.9 |
75.8 |
39.9 |
1.2 |
|
GX-T-15 |
34.93 |
35.03 |
35.03 |
35.03 |
20 |
20 |
20 |
21.5 |
21.5 |
23.5 |
82.9 |
43.5 |
1.3 |
|
GX-T-16 |
38.10 |
38.2 |
38.2 |
38.2 |
22 |
22 |
22 |
23.1 |
23.1 |
25.1 |
90.1 |
47.1 |
1.4 |
|
GX-T-17 |
41.28 |
41.38 |
41.38 |
41.38 |
24 |
24 |
24 |
24.6 |
24.6 |
26.6 |
97.3 |
50.6 |
1.5 |
|
GX-T-18 |
44.45 |
44.55 |
44.55 |
44.55 |
26 |
26 |
26 |
26.2 |
26.2 |
28.2 |
104.5 |
54.2 |
1.5 |
|
GX-T-19 |
50.80 |
50.9 |
50.9 |
50.9 |
28 |
28 |
28 |
29.4 |
29.4 |
31.4 |
114.8 |
59.4 |
1.8 |
|
GX-T-20 |
53.98 |
54.08 |
54.08 |
54.08 |
30 |
30 |
30 |
31.0 |
31.0 |
33.0 |
122.0 |
63.0 |
1.8 |
|
GX-T-21 |
63.50 |
63.6 |
63.6 |
63.6 |
32 |
32 |
32 |
35.8 |
35.8 |
37.8 |
135.5 |
69.8 |
2.0 |
|
GX-T-22 |
66.70 |
66.8 |
66.8 |
66.8 |
34 |
34 |
34 |
37.4 |
37.4 |
39.4 |
142.7 |
73.4 |
2.0 |
|
GX-T-23 |
79.40 |
79.5 |
79.5 |
79.5 |
36 |
36 |
36 |
43.7 |
43.7 |
45.7 |
159.4 |
81.7 |
2.0 |
|
GX-T-24 |
105.00 |
105.1 |
105.1 |
105.1 |
38 |
38 |
38 |
56.5 |
56.5 |
58.5 |
189.0 |
96.5 |
2.5 |
